UNWINDER UNIT
Product Diameter: 1500mm (max weight 3500kg)
Product Width: 3200mm (max) – 1000mm (min)
Bobbin Diameter: 76/152 mm mechanical clamping adapter
Tension Control: Air brake 6 (2pcs)
Measuring system: Denzir system
Edge control: Web control system
Loading system: HYDRAULIC supported shaft-less system
(up/down and right/left hydraulic system) (wired control available)
WINDING UNIT
Product Max Diameter: 600mm
Bobbin Diameter: 76 mm air shaft (aluminum body) (2pcs)
Measuring system: Prosser reference winding
Unloading system: Manual
WORKING WIDTH & CUTTING WIDTH
WORKING SPEED: 300 mt/min
CUTTING SYSTEM: Rotary blade (3 tk)-upper blade air system
MAX PRODUCT WIDTH: 3200 mm
MIN CUTTING WIDTH: Rotary blade 100 mm (side burr removal)
Product (workable product): 30 -120 gr/m2
Max machine speed varies according to the width and type of the product being cut
